61302011121
Manufacturer:
Wurth Electronics
Mfr.Part #:
61302011121
Datasheet:
Description:
Headers and Wire Housings Through Hole Male Pin Number of Positions:20 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Termination | Solder |
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 20 |
| Packaging | Bulk |
| RoHS | Compliant |
| Lead Pitch | 2.54 mm |
| REACH SVHC | Unknown |
| Contact Plating | Gold |
| Contact Material(Contact Finish) | Copper |
| Pitch | 2.54 mm |
| Current Rating | 3 A |
| Orientation | Vertical |
| Operating Supply Voltage | 250 V |
| Color | Black |
| Gender | Male |
| Number of Contacts | 20 |
| Connector Type | Male Pin |
| Number of Positions | 20 |
| Number of Rows | 1 |
| Contact Resistance | 20 mΩ |
| Contact Mating Length | 5.9944 mm |
| Mating Post Length | 6 mm |
| Termination Post Length | 3 mm |
Stock: 1065
Distributors
pcbx
pcbxUnit Price$0.68848
Ext.Price$0.68848
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.68848 | $0.68848 |
| 10 | $0.58506 | $5.85060 |
| 25 | $0.48778 | $12.19450 |
| 50 | $0.40658 | $20.32900 |
| 100 | $0.36997 | $36.99700 |
| 300 | $0.35355 | $106.06500 |
| 500 | $0.33787 | $168.93500 |
